9.3. Summary of Trackers

With this report we have the possibility to obtain a list of the trackers by area, as well as the power (kWp) associated with each one. In addition, the summations are shown both by zones and the total of the project.
          Both the number of panels and the total final power are calculated according to the characteristics of the type of tracker, which has been previously defined in the Trackers > Type of Trackers.
In the previous image you can see the characteristics of a type of tracker to which, in the Panels section, the distribution and power of the same have been defined.
