Define Grade (Pipes)

          This command will allow you to define a grade with a certain depth with respect to the longitudinal.
          The command will request the longitudinal from which the grade will be generated and the difference in minimum and maximum dimension with respect to it.
          A grade will be calculated which meets the requirement of difference in dimension and with the minimum number of vertices.
