In this option we have the possibility of assigning the road marks to the elements of the road.
Like the previous elements, they are defined by pks, indicating for each of them the associated line type. In the image we can see a road marking assignment up to pk 507.067.
For each element of the road, Alignment,Lane Separation and Edge o Road we have the possibility to assign a certain road mark. Likewise, in the Side column, we specify the application side of the road marking.
Road marks: We configure the different road markings available. For more details consult the Customization Manual, in the Aligment section.
